2 Door Steel School Lockers - Hefeng

Product Data:

Model JF-2B1A
Name 2 Door Steel School Lockers
Product Size H1820 * W608 * D420mm
Package Size H1755 * W640 * D100mm = 0.1123CBM
Loading Qty 605 Pcs/40’HQ, 249 Pcs/20’GP
Material Heavy gauge cold-rolled steel plate.
Pre-treatment Water wash, chemical wash, phosphating.
Finish Durable electrostatic powder coating.
Colour Classic grey, two-tone option, or other customized colour.
Fittings Chrome coat rod, index holder, keyed camlock or padlock latch.
Accessories 4 keys, assembly screws.
  • Knock down and easy assembling construction.
  • Different locks for option.
  • Different colour for option.
  • Different air ventilation for option.
  • Standing legs available.
  • Sloping top available.
  • Master key available.
  • Core removable key available.

9 steps to assemble the 2 Door Steel School Lockers.

  1. Connect the left side plate with back plate by self-tapping screws(5×12).
  2. Connect the right side plate with back plate.
  3. Fix the door frame onto both of the side plates.
  4. Install the bottom plate firstly, and put the lower division plate into the locker.
  5. Install the top plate with screws(5×12), and then install the division plate.
  6. Install the small shelves as shown in the picture.
  7. Install the hanging rods.
  8. Install the standing feet with screws(5×12).
  9. Adjust each part till fit well after installation.
